    Construction Site 3000Kg Rack And Pinion Hoist

    Ask Lasest Price
    Brand Name : KANGBO
    Model Number : Rack and pinion hoist SC300BG KP-B15 SC300/300BG KP-B16
    Certification : TUV
    Price : Negotiate
    Payment Terms : T/T, L/C
    Supply Ability : 150 sets
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    Construction Site 3000Kg Rack And Pinion Hoist

    Construction Site 3000Kg Rack And Pinion Hoist


    Rack And Pinion Hoist Introduction


    1. It is equipped with fully safety devices to guarantee the safe working;

    2. Stable running and comfortable adaptability;

    3. The transmission system adopts two-drive motors and three-drive motors. Planar double-eveloping worm gear reducer is adopted ensuring the high efficiency, max payload and long service life;

    4. Simple electrical control system, easy operation and convenient maintenance withlow failure rate.


    Rack And Pinion Hoist Design


    It is the truly modular rack and pinion hoist design, so the elevator drive devices and cars are generic and interchangeable.
    The modular and standardizing system makes the Kangbo construction elevators be flexible, efficient, safe, productive, low energy consumptive and ownership cost, making them the best choice for both construction and rental companies.

    Multiple choice of construction lifts car doors or ramps is available.


    Rack And Pinion Hoist Production and Materials


    KANGBO implements the true modular design of rack and pinion hoists, standardization and fine finishing of lifts parts and spare parts, and assembly line production. The material elevator components are versatile and universal.
    Main structure frame are made of 16Mn and Q345 high strength cold roll steel plate, cut by laser, process by CNC machines in tool fixtures, welded by robots.
    The construction lift cage roof is made by a full steel plate, and the edges are totally welded, to ensure no water leakage and high strength.


    Rack And Pinion Hoist Parameters


    Item & Article No.SC300BG, KP-B15; SC300/300BG, KP-B16
    Payload capacity3,000 kg
    Lifting speed0–60 m/min.
    Max. lifting height250/400 m*
    Cage width (internal)1.5 m
    Cage length (internal)3.2 m
    Cage height (internal)2.35 m
    Motor controlFrequency Control
    Engine power3x23 kw
    GearboxHelical reducer
    Safety device typecentrifugal brake
    Power supply range380–500 V, 50 or 60 Hz, 3 phase
    Mast SectionSquare column 650*650*1508 mm with bolted rack
    Rack module8
