Supply the world class Construction Lifts for the users. TUV approved products. Xiamen Comwinning Imp. & Exp. Co., Ltd. / KANGBO MACHINERY GROUP
7 Years
| Ask Lasest Price | |
| Brand Name : | KANGBO |
| Model Number : | Construction Site Elevator SC200BZ MP-B07 SC200/200BZ MP-B08 |
| Certification : | TUV, CCC |
| Price : | Negotiate in USD |
| Payment Terms : | T/T, L/C |
| Supply Ability : | 300 sets per month |
| Delivery Time : | 25-30 days |
Adjustable Speed 0–46 M/Min SC200/200BZ Rack And Pinion Hoists
Rack And Pinion Hoists Description
1. Construction Hoist have features as good quality, long life, wide applicationrange and convenient for maintenance.
2. Construction Hoist's gearing adopts imported bearing, enameled cable and oil seal.
3. Construction Hoist's electric parts adopt products from world renowned manufacturers such as Schneider, Siements and LG.
4. Construction Hoist's racks and pinion adopts special material and heat-treatment technique, which prolong the life of these parts.
Rack And Pinion Hoists Production and Materials
KANGBO implements the true modular design of rack and pinion
hoists, standardization and fine finishing of lifts parts and spare
parts, and assembly line production. The material elevator
components are versatile and universal.
The construction material elevator structural parts are made of
16Mn and Q345 high strength steel.
The construction lift cage roof is made by a full steel plate, and
the edges are totally welded, to ensure no water leakage and high
strength.
Rack And Pinion Hoists Features and Advantages
* The modular and standardizing system makes the Kangbo
construction elevators be flexible, efficient, safe, productive,
low energy consumptive and ownership cost, making them the best
choice for both construction and rental companies.
* The material hoist runs without vibration or trembling. The
Construction Site Elevator starts and stops without surging or
jerking.
Rack And Pinion Hoists Technical Data
| Item & Article No. | SC200BZ, MP-B07; SC200/200BZ, MP-B08 |
| Payload Capacity | 2,000 KG per Cage |
| Lifting Speed | 0–46 m/min. |
| Max. Lifting Height | 450 m |
| Cage Size (internal) | 3.2(Length)*1.5(Width)*2.35(Height) Meter per Cage |
| Cage Doors | 3 Doors, Entry Door + Exit Door + Side Door |
| Motor Control | FC (Frequency Control) |
| Engine Power | 2x15 KW per Cage |
| Gearbox | Helical Gearbox |
| Safety Device Type | Centrifugal Brake |
| Power Supply Range | 380–500 V, 50 or 60 Hz, 3 Phase |
| Type of Mast | Square Column 650*650 mm with Bolted Rack |
| Length Mast Section | 1.508 m |
| Rack Module | 8 |
|
