Supply the world class Construction Lifts for the users. TUV approved products. Xiamen Comwinning Imp. & Exp. Co., Ltd. / KANGBO MACHINERY GROUP
7 Years
| Ask Lasest Price | |
| Brand Name : | DABIAO |
| Model Number : | BHFS-5-16A/80 |
| Certification : | CE |
| Price : | Negotiate |
| Payment Terms : | T/T, L/C |
| Supply Ability : | 20000 meters per month |
| Delivery Time : | 5-8 days |
BHFS-5-16A/80, 16mm² Busbar Power Supply Device For Rack And Pinin Hoists
Brief
The conductive rails of busbar are installed in parallel along the
running track of the rack and pinion elevator lifts. And the
Current Collectors are assembled on the Lifts to collect the power
from the conductor.
The Current Collector operates synchronously with the moving hoist,
and the power supply is obtained from the conductor at any time
and/or position to make the hoist move continuously. The Sliding
Contact Line is the device that composed of Current Collector,
Conductive Conduits which hold Conductive Rails, and relative
components.
Structure and main components /parts
As a power supply device for moving Construction Lifts, the
integrated busbar, Sliding Contact Line is composed of two main
parts. That is, Conductive Conduits and the auxiliary assembly,
Current Collector and the auxiliary assembly.
Features
*Safety:
It is wind-proof, rain-proof and snow-proof. The use of the device will not be affected by the wind, rain or other bad weather. Its good insulation performance ensures no harm to the maintenance personnel when they touch the Contact Conduits.
*Reliability:
The Conductive Rails of Slide Contact Line are made of aluminum
alloy profile, with excellent conductivity, rapid heat dissipation,
low impedance and line loss. The carbon brushes of collectors are
made of metal graphite material with high conductivity and high
wear resistance. The moving of Current Collector is flexible and
with good directional performance. The contact arc and the series
arc phenomenon are effectively controlled.
*Economy:
Sliding Contact Line System is simple in structure and its Conductive Rails are with high density, low resistivity and low loss, can reduce the loss of electric energy. Its length can be added according to the height of hoist mast, which solves the problems of short work life and easy theft of the cables. At the same time, the Conductive Conduits can be segmented replaced, no need to change the whole cable in the case of local damage.
*Convenience:
The Sliding Contact Line integrates multistage Bus Bar in a Conductive Conduit, is easy to assembe. Its fixing brackets, connecting clamps and suspension devices, etc. are provided with standard components, very easy to assemble/dismantle, commissioning and repair.
|
|
